Automatic Instant Noodles Packing Machine Stainless Steel Pillow
Packing Equipment
Description:
This machine is suitable for automatic packaging of instant
noodles, biscuits, ice cream bar,snack, medicine, soaps, tissues,
chocolate, frozen food, adhesive tape, industrial parts, etc.
It has advantage of high packing efficiency and good quality. It
adopts inverter to adjust speed, human machine interface to
operate, PLC to control. and photoelectric to monitor and control
each station automatically, so that once something unexpected
happen, it will stop and display the reasons automatically, which
can solve the troubules in time.
Main Performance and Features:
1. Compact structure, stable performance, simple operation.
2. Dual frequency conversion control, bag length can be set and cut
in one step. Saving time and film.
3. It adopts imported electric appliance, touch person-machine
interface. Convenient parameter setting.
Self-checking function, trouble can be read easily.
4. Subscript sensitivity photoelectric eye tracking make sure more
accurate location of all letters.
5. Dependent temperature PID controlling suitable for varies
materials of packaging films.
6. Positioned stop function, without sticking knife or wasting
film.
7. Clean rotation system, more reliable operation and more
convenient maintenance.
8. The control is realized through soft ware, convenient for
function adjusting and technology
upgrading.Never lag behind.
Main technical parameters:
| Model | BC-250 |
| Max. Film Width | 550mm |
| Max. Packaging Capacity(according to its material) | 80bag/min) |
| Film Thickness | 0.03-0.07mm |
| Bag Length | 90-300mm/180-600mm |
| Packing Width | 60-220mm |
| Packing Height | ≤120mm |
| Total Power | 208kw 220v |
| Overall Dimention(L×W×H) | (4200×1000×1450) |
| Weight | 1000KG |
